TAIL LIGHT

WIRING HARNESS FOR SUZUKI RG 500 1987

RIGHT SWITCH - HANDGRIP (MODEL G) REFER TO FIG.43 (F-10) FOR MODEL H

(1) 36610-20AK0-000

HARNESS,WIRING

(2) 36618-30610-000

DUST COVER
BOOT,WIRING HARNESS

(3) 36920-02200-000

CUSHION
COVER,HARNESS

(4) 09404-08420-000

CLAMP
LEAD WIRE CLAMP (L:67)

(4) 09404-06039-000

CLAMP L:65
CLAMP (L:60) REFER TO FIG.6A (C-4) FOR MODE

(5) 09407-05406-000

CLAMP (L 118)
CLAMP (L:103)

(6) 09407-25401-000

CLAMP
CLAMP (L:235)

(6) 09407-14403-000

CLAMP
CLAMP (L:95)

(6) 09407-18402-000

CLAMP
CLAMP (L:185)

(7) 36619-04A00-000

CLAMP,HANDLE SWITCH

(8) 02112-0610B-000

SCREW CENTER SHAFT
SCREW

(9) 08321-0106A-000

.LOCK WASHER

(10) 36851-38401-000

WIRE,WATER TEMP GAUGE LEAD

(11) 36740-24B01-000

FUSE CASE ASSY
BOX ASSY, MAIN FUSE

(12) 09481-20101-000

FUSE
FUSE (20A)

(13) 36791-20A00-000

BRACKET,FUSE

(14) 37100-16702-000

IGN SWITCH & S-LOCK
SWITCH ASSY,IGNITION

(14) 37110-16710-000

SWITCH ASSY,IGNITION

(15) 07130-06167-000

.BOLT

(16) 08321-01067-000

.LOCK WASHER

(17) 37145-16700-000

KEY,BLANK

(18) 37740-04A10-000

BRAKE LAMP SWITCH
SWITCH ASSY, STOP LAMP

(19) 09443-06012-000

SPRING

(20) 38500-20A70-000

38500-20A70-000
HORN ASSY

(20) 38500-20A80-000

HORN ASSY

(21) 01500-0612A-000

BOLT
BOLT,EXTENSION,FRONT

(22) 08321-0106A-000

.LOCK WASHER

	Part number	Description	Qty
# 1	36610-20A01-000 3661020A01000	HARNESS, WIRING	Not available	£0,00
# 2	36618-30610-000 3661830610000 3661830610000	DUST COVER BOOT, WIRING HARNESS	£9,32
# 3	36920-06400-000 36920-02200-000 3692006400000	CUSHION COVER, HARNESS	£5,44
# 4	09404-06402-000 09404-06039-000 0940406402000	CLAMP L:65 CLAMP (L:60) REFER TO FIG.6A (C-4) FOR MODE	£1,94
# 4	09404-08402-000 09404-08420-000 0940408402000	CLAMP LEAD WIRE CLAMP (L:67)	£4,03
# 5	09407-05405-000 09407-05406-000 0940705405000	CLAMP (L 118) CLAMP (L:103)	£2,59
# 6	09407-11401-000 09407-14403-000 0940711401000	CLAMP CLAMP (L:95)	£2,84
# 6	09407-18402-000 0940718402000 0940718402000	CLAMP CLAMP (L:185)	£1,79
# 6	09407-25401-000 0940725401000 0940725401000	CLAMP CLAMP (L:235)	£3,23
# 7	36619-04A00-000 3661904A00000 3661904A00000	CLAMP, HANDLE SWITCH	Not available	£0,00
# 8	02112-06104-000 02112-0610B-000 0211206104000	SCREW CENTER SHAFT SCREW	£2,44
# 9	08321-21064-000 0832121064000	.LOCK WASHER	Not available	£0,00
# 10	36851-38401-000 3685138401000 3685138401000	WIRE, WATER TEMP GAUGE LEAD	Not available	£0,00
# 11	36740-09301-000 36740-24B01-000 3674009301000	FUSE CASE ASSY BOX ASSY, MAIN FUSE	£38,03
# 12	09481-20101-000 0948120101000 0948120101000	FUSE FUSE (20A)	£2,69
# 13	36791-20A00-000 3679120A00000 3679120A00000	BRACKET, FUSE	Not available	£0,00
# 14	37100-16710-000 3710016710000	IGN SWITCH & S-LOCK SWITCH ASSY, IGNITION	Not available	£0,00
# 14	37110-16710-000 3711016710000 3711016710000	SWITCH ASSY, IGNITION	Not available	£0,00
# 15	37152-47011-000 07130-06167-000 3715247011000	.BOLT	£4,85
# 16	08321-21067-000 08321-01067-000 0832121067000	.LOCK WASHER	£2,44
# 17	37145-16700-000 3714516700000 3714516700000	KEY, BLANK	£15,72
# 18	37740-14A00-000 37740-04A10-000 3774014A00000	BRAKE LAMP SWITCH SWITCH ASSY, STOP LAMP	£34,66
# 19	09443-06012-000 0944306012000 0944306012000	SPRING	£4,85
# 20	38500-20A70-000 3850020A70000 3850020A70000	38500-20A70-000 HORN ASSY	Not available	£0,00
# 20	38500-20A80-000 3850020A80000 3850020A80000	HORN ASSY	Not available	£0,00
# 21	01107-06125-000 01500-0612A-000 0110706125000	BOLT BOLT, EXTENSION, FRONT	£1,81
# 22	08321-21064-000 0832121064000	.LOCK WASHER	Not available	£0,00

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Suzuki, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
